6-2 2002 Buell S3T: Drive/Transmission
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Access Door Mounting Bolts 13-17 ft-lbs 18-23 Nm LOCTITE THREADLOCKER 243 (blue)
Clutch Inspection Cover TORX
Screws with Washers
7-9 ft-lbs 10-12 Nm
Clutch Mainshaft Nut
70-80 ft-lbs 95-109 Nm
LOCTITE THREADLOCKER 262 (red),
left hand
threads
Countershaft Retainer
TORX Screw
13-17 ft-lbs 18-23 Nm
LOCTITE THREADLOCKER 243 (blue)
Engine Sprocket Nut 190-210 ft-lbs 258-285 Nm LOCTITE THREADLOCKER 262 (red)
Isolator TORX Bolts (Rear)
63-70 ft-lbs 85-95 Nm
LOCTITE THREADLOCKER 262 (red), LOCTITE
ANTI-SEIZE under bolt heads
Primary Chain Adjuster Locknut 15-18 ft-lbs 20-24 Nm on interior of chaincase
Primary Chain Adjuster Locknut 20-25 ft-lbs 27-34 Nm on exterior of chaincase
Primary Chain Inspection Cover
Screws
40-60
in-lbs
5-7 Nm
Primary Cover Screws 100-120
in-lbs
11-14 Nm 3 lengths
Large primary cover screws 16-28 ft-lbs 22-38 Nm
Rear Shock Mounting Bolt
(Front)
40-45 ft-lbs 54-61 Nm
metric
Rear Shock Mounting Bolt
(Rear)
30-33 ft-lbs 41-45 Nm
metric
Shifter Lever Pinch Screw 59-66
in-lbs
7-8 Nm
Shifter Lever Mounting Bolt 27-29 ft-lbs 37-39 Nm
Shifter Shaft Assembly Locknuts 90-110
in-lbs
10-12 Nm bottom nut first, same torque for top
Tie Bar Bolts 30-33 ft-lbs 40.7-44.7 Nm
Transmission Detent Plate Nut 13-17 ft-lbs 17.6-23.0 Nm
Transmission Drain Plug 14-21 ft-lbs 19.0-28.5 Nm remove debris from end
Transmission Sprocket Nut
See note
LOCTITE THREADLOCKER 262 (red),
left hand
threads
, special torque turn method
Transmission Sprocket Screws 90-110
in-lbs
10.2-12.4 Nm replace after 3 removals
