2002 Buell S3T: Fuel System 4-1
HOME
SPECIFICATIONS 4.1
TORQUE VALUES
FUEL TANK CAPACITY GALLONS LITERS
Tot al (including Reserve) 5.4 20.44
Reserve 0.4 1.51
Low Fuel Indicator Light at 0.4 1.51
ADJUSTMENTS
Normal Idle Speed 850-1050 RPM
ITEM TORQUE NOTES
Backplate Mount Bolts 3-5 ft-lbs 4-7 Nm LOCTITE THREADLOCKER 243 (blue)
Canister Mounting Clamp
Screws
6-8 ft-lbs 8-11 Nm
Cylinder Head Breather Bolts 10-15 ft-lbs 14-20 Nm HYLOMAR
Fuel Cap Flange Screws 22-25
in-lbs
2.5-2.8 Nm special pattern to tighten
Fuel Pump Stud Nuts 68-75
in-lbs
8-9 Nm LOCTITE THREADLOCKER 243 (blue)
Fuel Supply Valve Screws 25-27
in-lbs
2.8-3.1 Nm
Fuel Tank Mounting Bolt 18-23 ft-lbs,
then wait 5
min. and
retighten to
18-23 ft-lbs.
24-31 Nm special procedure
Ignition Bracket Screw 25-30 ft-lbs 34-41 Nm
Intake Manifold Screws 6-10 ft-lbs 8-14 Nm
Snorkel Plate Screws 6-8 ft-lbs 8-11 Nm LOCTITE THREADLOCKER 243 (blue)
Tie Bar Bolts 30-33 ft-lbs 41-45 Nm
