Buell 2002 S3T - Page 288

2002 Buell S3T: Fuel System 4-73
HOME
Figure 4-58. Fuel Pump Circuit
b0640x4x
R
R
R/GY
R/BK
R/GY
R/BK
R/BK
R/BK R/BK
GY/O
Ignition 20A
Memory 15A
Spare 15A
Lights 15A
Instruments 15A
Accessory 15A
Ignition
Switch
[33]
Engine Stop
Switch [22]
TN/W
Ignition Relay
W/BK
GY/O
To Main Circuit
Breaker
To Starter
Interlock Circuit
GY
Low fuel
lamp
GY
BN/Y
Electronic Control Module
(ECM)
Connector [10] Connector [11]
O
O
Instruments
[39]
GY
BN/Y
BK
Y/R
Fuel
Pump
[86B]
[86A]
Table 4-23. Wire Harness Connectors in Figure 4-58.
NO. DESCRIPTION TYPE LOCATION
[10] ECM (black) 12-place Deutsch under tail section
[39] Instruments 10-place Multilock under fuel cell
[86] Fuel Pump 4-place Packard above rear cylinder head, left side
