7-2 2002 Buell S3T: Electrical
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Battery Terminal Hardware 60-96
in-lbs
7-11 Nm metric
Ignition Coil Mounting Screws 4-6 ft-lbs 5-8 Nm
Inner Cover Screws 12-20
in-lbs
1.4-2.3 Nm
Neutral Indicator Switch 3-5 ft-lbs 4-7 Nm LOCTITE THREADLOCKER 243 (blue)
Rotor Mounting Bolts 90-110
in-lbs
10-12 Nm LOCTITE THREADLOCKER 243 (blue)
Spark Plugs 11-18 ft-lbs 15-24 Nm
Starter Battery Positive
Cable Nut
60-85
in-lbs
7-10 Nm
metric
Stator Mounting Screws
30-40
in-lbs
3.4-3.5 Nm
T- 27 TORX with retaining compound, replace after
removal
Switchgear Housing Screws
(Left Side)
25-33
in-lbs
3-4 Nm
metric
Switchgear Housing Screws,
(Right Side)
12-17
in-lbs
1-2 Nm
metric
