2002 Buell S3T: Electrical 7-13
HOME
Starter Test (Part 2 of 2)
CONDITION: Sidestand down, key ON, transmission in gear and clutch disengaged
YES
YES
Repair open on TN/W
wire between Diode 2
and ignition relay.
Check for ground on
TN/GN wire of clutch
switch connector [95].
Ground present?
Check for ground on TN/W wire
of Diode 2. Ground present?
Check for ground on
TN/GN wire of Diode 2.
Ground present?
YES
Check Diode 2 with
ohmmeter. Diode OK?
YES
Diode installed
backwards.
Reverse polarity.
Replace
diode.
YES
Repair open on TN/
GN wire between
connector [95] and
Diode 2.
NO
Replace clutch
switch.
Check for ground on BK
wire of connector [95].
Ground present?
NO
NO
NO
Repair open on
BK wire between
connector [95] and
ground.
NO
5070
5071
5072
5073
5074
5075
1
2
To Next Page
