3-4 2006 Buell Lightning: Engine
HOME
TORQUE VALUES
Table 3-15. Pinion Shaft Bearing Specifications
PINION SHAFT BEARING NEW COMPONENTS SERVICE WEAR LIMITS
Pinion shaft journal diameter
1.2496-1.2500 in.
31.7398-31.7500
mm
1.2496 in. (min) 31.7398 mm (min)
Outer race diameter in right
crankcase
1.5646-1.5652 in.
39.7408-39.7561
mm
1.5672 in. (max) 39.8069 mm (max)
Bearing running clearance 0.00012-0.00088 in.
0.00305-0.02235
mm
Fit in cover bushing (loose) 0.0023-0.0043 in. 0.0584-0.1092 mm 0.0050 in. 0.1270 mm
ITEM TORQUE NOTES
Air scoop fastener at oil cooler 48-72
in-lbs
5.4-8 Nm page 3-76
All tie bars 25-27 ft-lbs 33.9-36.6 Nm page 3-14
Anti-rotation screws (lifter) 55-65
in-lbs
6-7 Nm page 3-86
Clutch cable wire form fastener 84-92
in-lbs
9.5-10.4 Nm page 3-15, 3-40
Crankcase 5/16 in. screws 15-19 ft-lbs 20-26 Nm page 3-104
Cylinder head screws
Special procedure, Special pattern to tighten,
page 3-59
Cylinder studs 10-20 ft-lbs 14-27 Nm Special method to tighten, page 3-105
Exhaust header nuts 72-96
in-lbs
8.1-10.8 Nm page 3-14
Feed oil line at rear of oil pump 27-29 ft-lbs 36.6-39.3 Nm page 3-36
Front isolator bolt 49-51 ft-lbs 66-69 Nm page 3-14
Front isolator bracket mounting
fastener
49-51 ft-lbs 66.4-69.1 Nm page 3-14, 3-33
Gearcase cover screws 80-110
in-lbs
9-12 Nm Special pattern to tighten, page 3-91
Ignition coil fasteners 120-144
in-lbs
13.6-16.3 Nm page 3-42
Oil cooler oil line clamp 12-36
in-lbs
1.3-4 Nm page 3-38, 3-76
Oil cooler feed oil line at oil
cooler
19-21 ft-lbs 26-28 Nm page 3-38, 3-76
Oil cooler return oil line at crank-
case
15-17 ft-lbs 20.3-23 Nm page 3-38
Oil cooler return oil line at oil
cooler
19-21 ft-lbs 25.8-28.5 Nm page 3-38, 3-76
Oil filter adapter 96-144
in-lbs
11-16 Nm LOCTITE 243, page 3-84
Oil line clamp at starter motor 40-50
in-lbs
5-5.5 Nm page 3-36
Oil line fittings at swingarm 108-156
in-lbs
12-17.6 Nm page 3-74
Oil line p-clamp fastener 48-72
in-lbs
5.4-8 Nm page 3-36
Oil pressure signal light switch 50-70
in-lbs
6-8 Nm page 3-84
Oil pump cover screws 70-80
in-lbs
8-9 Nm TORX, page 3-83
Oil pump mounting screws 125-150
in-lbs
14-17 Nm page 3-83
