2006 Buell Lightning: Engine 3-5
HOME
Pinion shaft nut 19-21 ft-lbs 26-29 Nm page 3-90
Piston jet TORX screws 25-35
in-lbs
2.8-4 Nm Loctite 222, page 3-93
Pushrod cover screw 30-40
in-lbs
3-5 Nm page 3-86
Rear isolator assembly fasteners 25-27 ft-lbs 33.9-36.6 Nm page 3-30
Rear isolator bolt 25-27 ft-lbs 33.9-36.6 Nm page 3-33
Rear muffler bracket 32-36 ft-lbs 43.4-48.8 Nm page 3-34
Reed valve stop fastener 5-7
in-lbs
0.6-0.8 Nm page 3-79
Return oil line at top front oil
pump
22-24 ft-lbs 29.8-32.5 Nm page 3-36
Rocker box cover screws 120-156
in-lbs
13.6-17.6 Nm page 3-61
Rocker box to head bolts 135-155
in-lbs
15-18 Nm Small fasteners, page 3-61
Rocker box to head bolts 18-22 ft-lbs 24-30 Nm Large fasteners, page 3-61
Rocker box to head screws 135-155
in-lbs
15-18 Nm Small screw, page 3-61
Sprocket cover fastener 12-36
in-lbs
1-4 Nm page 3-18, 3-43
Stabilizer bracket fastener 66-78
in-lbs
7.5-8.8 Nm page 3-76
Swingarm pivot shaft pinch bolt 17-19 ft-lbs 23-25.8 Nm page 3-31
Swingarm pivot shaft 24-26 ft-lbs 32.5-35.2 Nm page 3-31
V bracket to main frame 120-144
in-lbs
13.6-16.3 Nm page 3-14, 3-33
Vent oil line at gearcase cover 12-13 ft-lbs 16.3-17.6 Nm page 3-36
ITEM TORQUE NOTES
