Buell 2006LIGHTNING MODELS User Manual

7-14 2006 Buell Lightning: Electrical
HOME
Starter Test (Part 1 of 2)
CONDITION: Key ON, transmission in neutral and clutch engaged
YES
Repair open on TN/Lt.GN
wire between diode and
start relay.
YES
Check Diode with ohm-
meter. Diode OK?
Remove sprocket cover.
Check for ground at
neutral switch terminal.
Ground present?
Check for ground at TN/Y
wire on Diode. Ground
present?
YES
Diode installed backwards.
Reverse polarity.
Replace
diode.
YES
Repair open on TN/Y
wire between neutral
switch and Diode.
Replace neutral
switch.
NO
NO
NO
NO
5060
5061
5062
5063
5064
1
2
Depress starter button.
Does Starter work?
Check for ground on TN/Lt.GN wire of Diode.
Ground present?
NO
Neutral interlock OK.
See 2 of 2.
YES
