E-6 2006 Buell Lightning: Appendix E
HOME
Code 22 Test (Page 1 of 2)
Is the Active Intake System cable pinched or binding?
Is the solenoid stuck?
Remove solenoid connector [178A]
and inspect connections. Are all con-
nections tight and free of corrosion?
NO
YES
Repair as needed.
YES
Disconnect active solenoid
connector [178A] at solenoid.
Measure voltage at pin 2 with
key ON and Run/Stop switch
on. Is battery voltage present?
YES
Measure voltage at [178A] Pin
Battery voltage present?
NO
Measure resistance
between connector
[178A] pin 1 and [179B]
pin 1.
Continuity present?
NO
NO
Clean and repair
connections.
Disconnect active solenoid
connector [179B] at ECM.
Measure resistance at pin 2 to
chassis ground.
Resistance less than 10,000
ohms?
Repair short to voltage
in GY/O wire.
YES
NO
Repair open in
GY/O wire.
YES
NO
Repair short to
ground in W/GY wire.
Measure resistance between
connector [178A] pin 2 and
[179B] pin 2. (W/GY wire)
Continuity present?
Repair open in
W/GY wire.
YES
NO
Page 2
of
2
YES
DIAGNOSTIC NOTE
If DTC is historic, wiggle harness while performing
measurements in chart to locate intermittents.
Go to page 2
of 2
