Code 22 Test (Page 2 of 2)
Measure resistance from active intake solenoid pin 1
to pin 2 [178B] (use HD 41404 brown pins).
Continuity should be present, approximately less
than 4 ohms, nominal 2.4 ohms.
Replace solenoid.
NOYES
Connect battery voltage to [178B] pin 2 of active
intake solenoid. (Use HD 41404 brown pin and patch
cable). Hold throttle wide open. Observe throttle plate
and connect solenoid pin 1 to ground.
Does solenoid attempt to pull throttle almost closed?
NO
Hold throttle wide open. Energize
active intake solenoid. Does throttle
close to an angle less than 11
degrees?
YES
YES NO
Replace ECM. See CABLE ADJUSTMENT
in this section.
Replace solenoid.
