196 I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Sanitary fittings
10
10.7.2 Toilet with fixed seat (Thetford C-402)
Preparing toilet: Open the flap for the Thetford cassette and pull the retaining clip
upwards to remove the Thetford cassette.
Pull out the Thetford cassette as far as it can go.
Tip the Thetford cassette slightly and then pull it out completely.
Place the Thetford cassette upright.
Turn the drainage neck upwards.
Remove the cap of the drainage neck.
Z The Thetford cassette can only be taken out if the sliding trap is closed.
Fig. 229 Pulling the retaining clip
Fig. 230 Removing the Thetford cas-
sette
Fig. 231 Turning drainage neck
Z Never put the sanitary liquid directly in the toilet bowl.
