6.4 Light switch
6.4.1 Entrance area
The entrance area has light switches for the following lamps:
z Seating group lights (Fig. 60,1)
z Entrance lights (Fig. 60,2)
z Awning lights (Fig. 60,3)
z Living area lights (Fig. 60,4)
6.4.2 Interior
Depending on the model, the light switches are fitted at various points: directly
on the lamp itself (Fig. 62,1) or away from the lamp at easily accessible loca-
tions (Fig. 63,1).
Z The light switches shown in this section are examples. Depending on the
model, the type and allocation of the light switches may differ to those dis-
played here.
Fig. 60 Light switch Fig. 61 Awning light
Z The lamps shown in this section are examples. Not all lamps used in the
vehicle are shown. The examples are intended to clarify the possible posi-
tions for the light switches. The type and appearance of the light switches
can deviate from those shown here.
Fig. 62 Lamp (example), switch
mounted directly on the lamp
Fig. 63 Separate light switch
