41I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
During the journey
4
4.8.1 Seats (Aguti)
Rotating seats The seats can be rotated in any direction. The seats can only be locked in posi-
tion in the direction of travel.
Push both armrests upward.
Push the driver's seat/front passenger's seat backwards or into the central
position.
Operate the release lever (Fig. 17,3). The latch is released.
Rotate the seat.
Adjusting the armrest The height of the armrests is infinitely adjustable.
Turn the knurled wheel (Fig. 17,2) upwards or downwards.
Adjusting an appropriate
seating position
The position of the driver's and front passenger's seats can be adjusted. The
handles which are required for this purpose are positioned to the front, right or
left of the seat.
Pull the handle (Fig. 17,1). The seat can be moved forward or backward.
Release handle. The seat runner automatically locks into the desired posi-
tion.
Turn the knurled knob (Fig. 17,4). The angle of the backrest can be
adjusted.
4.8.2 Seats (Aguti-Liner)
Rotating the seat The seats can be rotated in any direction. The seats can only be locked in posi-
tion in the direction of travel.
Fig. 17 Driver's seat and front pas-
senger's seat
1 Lengthways adjustment
2 Armrest adjustment
3Rotating
4 Backrest adjustment
Fig. 18 Seat adjustment Fig. 19 Armrest adjustment
