82 I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Living
6
6.10.1 Heki skylight (mini and midi)
The Heki skylight is opened on one side only.
Opening:
Press the safety knob (Fig. 88,2) and pull the bar (Fig. 88,1) down with both
hands.
Pull the bar (Fig. 89,1) in the guides (Fig. 89,2) to the rearmost position
(Fig. 89,3).
Closing:
Use both hands to push the bar (Fig. 89,1) slightly upwards.
Push the bar back in the guides.
Push the bar upwards with both hands until it is above the safety knob
(Fig. 88,2).
Z The skylights are fitted with a blind or Roman shade and with an insect
screen or folding insect screen. After the latch has been released, the blind
and insect screen automatically spring back to the initial position by tensile
force. In order not to damage the tension mechanics, hold onto the blind or
insect screen and allow it to slowly return to the initial position. The Roman
shade and folding insect screen are made of thin woven fabric. In order not
to damage the Roman shade or the insect screen, grasp the respective
handle and carefully return it to the initial position.
Z Do not keep blinds closed over a longer period of time as that can cause
increased material wear.
Z If the blind or the Roman shade is completely closed, exposure to direct
sunlight can cause heat to accumulate between the blind/the Roman shade
and the skylight. The skylight could be damaged. For that reason, close the
blind/Roman shade only 2/3 of the way in direct sunlight. Open the skylight
slightly or move it to ventilation position.
Z Depending on the weather, close the skylights far enough to prevent mois-
ture from entering.
Z Do not climb on the skylights.
Z Before commencing the journey, close the skylights.
Z Before commencing the journey, check that the skylights are closed and
locked.
Z When leaving the vehicle, always close the skylights.
Fig. 88 Safety knob on the Heki sky-
light
Fig. 89 Heki skylight, guide
