Burstner I 2012 - Front Lights

222 I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Maintenance
12
12.8.1 Front lights
Low beam/main beam The bulbs are changed in the engine compartment.
 Open bonnet (see chapter 4).
 Put your hand behind the lamp holder (Fig. 254,1).
 Turn the lamp holder with the lamp in an anticlockwise direction and
remove.
 Turn bulb in an anticlockwise direction and remove from the holder.
 Put in a new bulb.
Direction indicator The bulbs are changed in the engine compartment.
 Open bonnet (see chapter 4).
 Put your hand behind the lamp holder (Fig. 255,1).
 Turn the lamp holder with the lamp in an anticlockwise direction and
remove.
 Remove bulb.
Fig. 253 Front lights
1Fog light
2 Daytime running light (LED)
3 Direction indicator
4 Low beam/main beam
Fig. 254 Low beam/main beam/parking
light
Fig. 255 Direction indicator
