Burstner I 2012 - Blind and Insect Screen

79I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Living
6
Opening:  If the blind is completely closed: Press handle (Fig. 83,2) downwards and,
at the same time, tilt it slightly inward. The blind can be taken out of the
locking devices situated on both sides of the window frame.
 If the blind is in an intermediate position: Pull the handle (Fig. 83,2) slightly
downwards until the locking device releases.
 Use handle to return blind slowly to its initial position.
Insect screen The insect screen is located in the upper blind box.
Closing:
 Pull insect screen at the handle (Fig. 83,1) down and hang it into the
locking devices (Fig. 83,3) situated on both sides of the window frame.
Opening:
 Press handle (Fig. 83,1) downwards and, at the same time, tilt it slightly
inward. The insect screen can be taken out of the locking devices situated
on both sides of the window frame.
 Use handle to return the insect screen slowly to its initial position.
6.9.6 Blind and insect screen
The windows are fitted with a blind and an insect screen. The blind can be
used separately.
Blind The blind is located in the bottom blind box.
Closing:
 Press handle (Fig. 84,4) and draw blind (Fig. 84,3) from the bottom to the
top up to the desired height.
 Release handle. The blind locks into the nearest locking position.
Opening:
 Clench handle (Fig. 84,4). The latch is released.
 Slowly return the blind (Fig. 84,3) to its initial position.
Insect screen The insect screen is located in the upper blind box.
Closing:
 Pull insect screen (Fig. 84,2) down until it touches the blind (Fig. 84,3), and
engage the closure latch (Fig. 84,1) in the locking device (Fig. 84,5).
Opening:
 Release the closure latch (Fig. 84,1).
 Slowly return insect screen into its initial position.
Fig. 84 Hinged window
