Burstner I 2012 - Roman Shades for Windscreen, Drivers Window and Front Passengers Window; Skylights

81I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Living
6
Opening:  Grip the Roman shade (Fig. 86,2) in the centre of the holding bar and
slowly push it to its initial position.
Insect screen The insect screen can be used separately from the Roman shade and can also
stay fully closed if required.
Closing:
 Grip the insect screen in the centre of the holding bar (Fig. 86,1), pull it out
and release it at the required position. The insect screen will stay in that
position.
Opening:
 Grip the insect screen in the centre of the holding bar and slowly push it to
its initial position.
6.9.9 Roman shades for windscreen, driver's window and front
passenger's window
Closing:  Grasp the handle (Fig. 87,2) of the Roman shades and draw carefully until
the magnetic catch keeps the Roman shades closed.
Opening:
 Using the handle, carefully push back the Roman shades.
 Push the handle (Fig. 87,2) onto the cap (Fig. 87,1). The Roman shade is
secured.
6.10 Skylights
Depending on the model, skylights with or without forced ventilation are fitted
to the vehicle. If a skylight is fitted without forced ventilation, the forced venti-
lation is performed using mushroom-shaped vents.
Fig. 87 Roman shade, driver's cabin
window
X The apertures for forced ventilation must always be kept open. Never
cover or block forced ventilations with objects such as e.g. a winter mat.
Keep forced ventilations clear of snow and leaves.
