200 I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Sanitary fittings
10
Activate the aeration knob with your thumb. The Thetford cassette empties.
Rinse the Thetford cassette thoroughly with fresh water.
Close drainage neck with the cap.
Return the drainage neck to its original position.
Prepare the Thetford toilet for use.
Push the Thetford cassette back to its original position.
Ensure that the Thetford cassette is secured by the retaining clip.
Lock the flap for the Thetford cassette.
10.7.3 Toilet (Dometic)
Preparing toilet: Open the flap for the sewage tank on the outside of the vehicle. Insert the
key into the locking cylinder of the push-button lock (Fig. 242,1) and turn a
quarter turn.
Remove the key.
Press both push-button locks (Fig. 242,2) simultaneously with your thumb
and open the flap.
Pull up the retaining clip (Fig. 243,3) and use the handle (Fig. 243,2) to lift
the sewage tank (Fig. 243,1) straight up.
Tilt the sewage tank slightly and remove fully.
Fig. 241 Inserting the Thetford cassette
Z The sewage tank (cassette) can only be taken out if the sliding trap is
closed.
Fig. 242 Flap for sewage tank Fig. 243 Sewage tank
