Living
6
Closing:  Rotate the hand crank until the wind-up skylight is closed. The wind-up sky-
light can be locked after rotating two or three more times.
 Check the locking mechanism. To do so, press your hand against the
acrylic glass.
Roman shade The Roman shade can be closed in any position, as desired. If the Roman
shade is locked with the insect screen, the insect screen is also moved along
on closing the Roman shade.
Closing:
 Pull the handle of the Roman shade (Fig. 92,3) and release in the desired
position. The Roman shade will stay in that position.
Opening:
 Slowly push the Roman shade at the handle to its initial position.
Insect screen If the insect screen is locked with the Roman shade, the Roman shade is also
moved along on closing the insect screen.
Closing:
 Pull insect screen at the handle (Fig. 92,1) to the opposite handle of the
Roman shade (Fig. 92,3) and allow to engage.
Opening:
 Press the handle of the insect screen (Fig. 92,1) at the back upwards and
detach the insect screen from the Roman shade (Fig. 92,3).
 Slowly push insect screen at the handle to its initial position.
6.11 Tables
6.11.1 Suspension table with changeable table leg
The suspension table size can be enlarged by inserting a table-top extension.
Extending:
 Open catches (Fig. 94,1).
 Raise the table-top (Fig. 93,2) slightly and pull it out as far as possible.
 Set down the table.
 Insert the table-top extension (Fig. 93,1) and secure it with the catch
(Fig. 94,1).
 Lift the table-top slightly and push back as far as possible.
 Secure the table-top with the catches.
Z The tables shown in this section are examples. Depending on the model,
the tables may differ from the the type displayed here.
Fig. 93 Suspension table Fig. 94 Catch
