Burstner I 2012 - Hinged Sunroof with Automatic; Hinges; Sliding Window with Lock

77I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Living
6
 Turn the catch lever (Fig. 80,3) a quarter turn towards the centre of the
window.
 Slightly open the hinged window outwards.
 Turn the catch lever a quarter turn towards the window frame. The locking
catch (Fig. 80,2) has to be moved into the recess of window catch
(Fig. 80,1).
During the journey, the hinged window may not be in "continuous ventilation"
position.
If it rains, the "continuous ventilation" hinged window position could lead to
splashing water penetrating the living area. Therefore, close the hinged win-
dows completely.
6.9.3 Sliding window with lock
Opening:  Press the lock (Fig. 81,2) upwards.
 Press handle (Fig. 81,1) and push it forward or backward at the same time.
 Open window half up to the required position.
Closing:
 Close the window as far as it can go.
 Push the lock downwards.
6.9.4 Hinged sunroof with automatic hinges
Fig. 81 Sliding window with pressure
lock
Z Open the window completely, to release the lock. If the locking device is
not released and the window is closed nevertheless, there is the danger of
the window breaking due to the massive counter-pressure.
Z When opening the hinged windows, ensure that there are no torsional
forces. Open and close the hinged windows evenly.
Z Do not open the hinged window if there is a risk of frost. The hinge rail could
be damaged.
