4.3 Reversing camera (partially special equipment)
Depending on the equipment, a reversing camera (Fig. 14,1 or Fig. 15,1) with
LCD monitor (Fig. 16,1) is installed in the vehicle.
When it is dark, the infrared LEDs of the reversing camera (Fig. 15,1) illumi-
nate the field of view.
If the engine is running or the ignition is switched on, the reversing camera and
LCD monitor switch themselves on automatically when you engage reverse.
If the engine is running or the ignition is switched on, the reversing camera and
LCD monitor can also be switched on manually via a pushbutton or a switch
on the display.
The system can also be switched off via a pushbutton or the "OFF" button on
the display.
Z Depending on the model, different monitor systems can be installed in the
vehicle. The function of the reversing camera is the same way for all sys-
tems.
Fig. 14 Reversing camera (example) Fig. 15 Reversing camera with
infrared illumination
Fig. 16 LCD monitor for reversing
camera (example)
Z Further information can be obtained in the manufacturer's instruction
manual.
