During the journey
4
Activation by engaging
reverse:
Switch on the ignition and start the motor.
Engage reverse. The display illuminates and the vehicle symbol appears in
the display. The parking distance control is ready to measure.
Activation by pressing the
On/Off button on the display
unit:
Press the On/Off button (Fig. 13,4). The display illuminates and the vehicle
symbol appears in the display. The parking distance control is ready to
measure.
Switching off:
Press the On/Off button (Fig. 13,4). The parking distance control can be
switched off at all times independent of the selected switch-on method
using the On/Off key.
Distance display The distance between the vehicle and the obstacle is issued in three ways:
The display (Fig. 13) shows the distance in steps of 5 cm. The shortest dis-
tance measured by a sensor is shown.
Black measurement field blocks in the graphical distance display show an
obstacle approaching.
In addition to the visual displays, an acoustic signal (melody) is emitted that
changes according to the distance. As the distance between the vehicle and
the obstacle grows shorter, so the length of time between the signals shortens
until it becomes one continuous sound.
Z When you switch on the ignition, the parking distance control runs a self-
test. If a sensor is defective, this is indicated on the display by rapid
flashing of the sensor position. The parking distance control continues to
function, with the exception of the defective sensor.
If the radio connection is faulty, this will be indicated on the display by
means of a transmission mast symbol. Distance measurement is then not
possible.
When reverse gear is disengaged, the transmission mast symbol is also
briefly displayed.
Z Further information can be obtained in the device manufacturer's instruc-
tion manual.
