198 I-Modell - 11/12 - Ausgabe 09/11 - 2096165 - BUE-0056-05EN
Sanitary fittings
10
Using the toilet: Fill the toilet bowl with some water. Press the flush button. Flushing con-
tinues as long as the button is pressed.
Use the toilet.
Open the sliding trap. To do this, turn the slide lever in an anticlockwise
direction.
Flush the toilet. Press the flush button.
After flushing close the sliding trap again. To do this turn the slide lever in
a clockwise direction.
Fig. 235 Pre-flush
Fig. 236 Operating the sliding trap
Fig. 237 Operating the flush
Z The Thetford cassette can only be taken out if the sliding trap is closed.
