Appendix A Assembly Drawings Page A-51
Table A-41: Shaft Encoder Assembly (9100188A)
Item Part Number Quantity Description Reference
1 609000 0.75” Shrink Wrap, 3/16” I.D.
2 614008 4 Male Contact, Pin
3 614009 1 Plug, Pin Housing
4 9100188 1 Shaft Encoder
Figure A-43: Shaft Encoder Assembly (9100188A)
