Installation 129
Figure 116: Fixing the gland nut
3. Connect the RJ45 plug into the main PSU port of the ODU (which can be either V1000, V2000,
V3000, or V5000).
Figure 117: Connecting the RJ45 plug
4. Rotate the gland clock wise to tightly fit the gland on the PSU port.
Warning
Ensure that the cable clamp is not attached/ tightened at this stage, this may cause
damage to the RJ45 or PCB.
