System Hardware 46
V2000 CN
Figure 29: External interfaces for V2000 CN
Table 12: External interfaces - V2000 CN
Port
name
Connector Interface Description
PSU RJ45 POE Input Passive PoE or 802.3at (two pairs or four pairs for
higher wattage)
100m/1000m/2.5G BASE-T
Ethernet
Data and management
AUX RJ45 POE Output Standard IEEE 802.3at POE
100m/1000m/2.5G BASE-T
Ethernet
Data and management
