Section 2—Installing the Scanner 3100 EFM
Overview
The Scanner 3100 ow computer is fully assembled at the time of shipment and ready for mounting. However, Cameron
recommends that operators congure the EFM prior to mounting if the instrument is to be installed in a hazardous area.
The enclosure must be opened to congure the device, either via keypad controls or via software, and once the instru-
ment is mounted in a hazardous area, the cover should not be removed unless the area is void of combustible gas and
vapors.
Hazardous Area Precautions
The Scanner 3100 is ATEX/IECEx-certied (Zone 1) and CSA-certied (Class I, Div. 1) for hazardous area use. Instal-
lation requirements vary, depending on the certication required. Carefully review the following hazardous area require-
ments before installing a Scanner 3100 in a hazardous area.
ATEX Installations (Conditions for Safe Use)
The ATEX-certied standard Scanner 3100 is fully compliant with European ATEX Directive 94/9/EC and has been
evaluated per the following standards:
• IECEx: IEC 60079-0:2011, Edition 6, IEC 60079-1:2007-04, Edition 6, IEC 60079-11:2006, Edition 5, and IEC
60079-31:2013, Edition 2
• ATEX: EN 60079-0:2012, EN 60079-1:2007, EN 60079-11:2012, EN 60079-31:2014
The following instructions apply to equipment covered by certicate numbers Sira15ATEX 1122X and IECEx SIR
15.0049X:
• When removing the conduit plug to t the data transfer socket to the communication adaptor and during data
transfer, the user/installer shall ensure that no explosive atmosphere is present. After data transfer has nished, the
conduit plug shall be retted in accordance with the relevant Code of Practice.
• Under rated conditions, the branching point at the entry point may reach 80 degC (176 degF); therefore, when
choosing cables and cable glands, this shall be taken into account.
• When removing or replacing the internal battery packs, this shall be done in accordance with the user instructions
provided by the manufacturer, and the user/installer shall ensure that no explosive atmosphere is present.
• The user/installer shall install this equipment taking into account any restrictions or special conditions for safe use that
are applicable to the previously certied devices that are used in its construction.
Wiring Precautions
CAUTION In accordance with EN60079-0, Clause 16.6, all cable and cable glands must be rated for 80 degC
(176 degF). The Scanner 3100 may be tted as a remote unit when all the cable entries are tted
with ameproof glands that have been suitably certied by a notied body.
RTD Assembly Options (for Gas and Liquid Flow Runs Only)
The process temperature input is typically supplied by an RTD installed in a thermowell downstream of the primary
differential pressure source. The location of the thermowell should conform to the relative standard to ensure accurate
measurement. Use only an RTD assembly that is tted with a suitably certied, Ex d IIC cable entry gland, such as the
ameproof RTD (Part No. 9A-X-TTXR-0003) listed in Table 7.1—Scanner 3100 EFM Parts, page 87.
