Table 7.1—Scanner 3100 EFM Parts
Qty. Part Number Description
ATEX-Approved Parts
1 9A-X-TTXR-0003 Assembly, RTD and Cable, Flameproof, 3500-mm Cable, 50-mm Probe,
ATEX-approved, for Line Sizes from 2 to 12 inches
1 50302004 Battery Pack, 2 D Batteries in Series, 7.2 V, Lithium, Stick Style, ATEX-approved
1 50302001 Assembly, External Explosion-proof Switch, with Extension, ATEX-approved,
Fits 3/4 in. Female Pipe Thread, Momentary Contact, Wired Ends (uses include
manual control of ow accumulation, and manual control of a triggered archive)
1 50302003 Assembly, External Explosion-proof Switch, with Extension, ATEX-approved, Fits
3/4 in. Female Pipe Thread, Momentary Contact, with Lockout Mechanism, Wired
Ends (uses include manual control of ow accumulation or manual control of a
triggered archive)
1 50301998 Assembly, External Explosion-proof Switch, with Extension, ATEX-approved, Fits
3/4 in. Female Pipe Thread, Toggle, Wired Ends (uses include pacing the display,
toggling a wireless transmitter on and off, resetting grand totals for ow run or
pulse input accumulations, unlatching a digital output, and resetting a latch on a
triggered archive)
1 50302000 Assembly, External Explosion-proof Switch, with Extension, ATEX-approved Fits
3/4 in. Female Pipe Thread, Toggle, with Lockout Mechanism, Wired Ends (uses
include pacing the display, toggling a wireless transmitter on and off, resetting
grand totals for ow run or pulse input accumulations, unlatching a digital output,
and resetting a latch on a triggered archive)
* Recommended spare part
** For router adapters with other voltage ratings, contact Cameron.
Table 7.2—Wireless Components
Qty. Part No. Description
1 76533628 Antenna Coupler, N Coax, Male-to-Male (Female Thread), ATEX-approved
1 2350765-01 Antenna Coupler, N Coax, Male-to-Male (Female Thread), CSA-approved
1 2350869-01 Antenna, Short-haul Wireless, 2.4 GHz, 1/2 Wave Dipole, N Male, Right-Angle
1 50279275 Antenna, Short-Haul Wireless, Remote-Mount, 9 dBi 2.4 GHz Omnidirectional,
32-in. long, N Female with pole-mount bracket (ts pole outside diameters up to
2-in.)
1 50278052 Bracket, Pipe-Mount for Remote-Mount Antenna (ts pipe with 2.375-in. outside
diameter)
1 76527410 Antenna Cable with Connectors, Short-haul Wireless, 10-ft, Type 400,
-40 degC to 70 degC (–40 degF to 158 degF)
1 76527411 Antenna Cable with Connectors, Short-haul Wireless, 20-ft, Type 400,
-40 degC to 70 degC (–40 degF to 158 degF)
1 76527412 Antenna Cable with Connectors, Short-haul Wireless, 30-ft, Type 400,
-40 degC to 70 degC (–40 degF to 158 degF)
1 50272454 Ethernet Router, Portable, USB-powered; 110 V/220 V-to-USB Adapter Included
(not required when PC-powered with USB cable)**
1 76528845 Ethernet Router, Portable, Integral Rechargeable Lithium-Ion Battery-powered
1 76528309 RJ-45 Ethernet Cable, 15-ft Molded Connector
1 50272960-05 Cable, Ethernet, 5 ft, for WiFi Communications Accessory for Multi-Scanner Sites
1 50272960 -10 Cable, Ethernet, 10 ft, for WiFi Communications Accessory for Multi-Scanner Sites
1 50272960-20 Cable, Ethernet, 20 ft, for WiFi Communications Accessory for Multi-Scanner
Sites
88
Section 7 Scanner 3100 EFM
