Table 1.2—Hardware Options
Control Switch (CSA-
or ATEX-Approved)
Explosion-proof switch*, momentary contact, ts 3.4 in. female pipe thread (uses include
pacing the display, toggling a wireless transmitter on and off, resetting ow run or pulse input
grand totals, unlatching a digital output, and resetting a triggered archive latch)
Explosion-proof switch*, toggle action, ts 3.4 in. female pipe thread (uses include manual
control of ow accumulation and manual control of a triggered archive)
*Switch can be ordered with a factory-installed mechanical lockout mechanism for preventing
unauthorized users from changing the switch position.
Remote-Mount Kit Stainless steel mounting kit for 2-in. poles (mounts to the side of the electrical enclosure)
RTD Temperature
Sensor
4-wire, 100-ohm explosion-proof RTD assembly suitable for CSA Class 1, Div. 1 installations
4-wire, Class A sensor encapsulated by a stainless steel sheath and attached to a 3500 mm
(11.48 ft) armoured cable
Thermowell Nominal 6.6 mm (0.26 in.) bore, 1/2-in. FNPT instrument connection
Consult factory for various materials, process connections, insertion lengths ,and options
5-Valve Manifold Consult factory for direct-mount or remote-mount manifold and materials
Portable Ethernet
Router
Supports connection of a PC or other browser-based device to a Scanner 3100 ow
computer. Connects to Scanner with RJ-45 cable and connect to PC via WiFi. Available in
USB- or battery-powered models. See Wireless Communications, page 13 for additional
WiFi solutions.
Customer Tag Stainless steel tag for customer-specied information, 3 in. × 3 in., wired on, 5 lines of text, 45
character per line maximum
Table 1.3—Scanner Companion Software
Important To download software or software user manuals, visit the Cameron website at
products.slb.com, select Scanner 3100 Series Wired and Wireless, and click on the link for the
desired software install/manual.
Scanner Logic
IDE
Creates Scanner Logic scripts (SLOGIC) and compiles them into a logic-controller program le
(SLBIN).
Performs live debugging on scripts, showing immediate and upcoming script sections to be
debugged.
Uses a high-level procedural programming language designed to build logic controllers. In this way,
the program resembles a state machine.
Scanner Data
Manager
Opens proprietary data les (.sdf) downloaded from the Scanner 3100 and provides tools for data
analysis, reporting, export and conversion
Presents data in tabular and trend views
Includes tools for customizing reports
ScanMap Creates custom Scanner 3100 Modbus register maps, including user-specied units, rates, and
register names for SCADA integration
Firmware-specic templates
Auto-generates protocol manual for printing or uploading to the web interface
ScanFlash Uploads rmware (BIN), conguration (SRF), Scanner Logic IDE le (SLBIN), and custom Modbus
register map (PMAP) les to the Scanner 3100
PC Requirements
Windows 7 or later operating system
1 GHz or faster 32-bit (x86) or 64-bit (x64) processor
1 GB RAM (32-bit) or 2 GB RAM (64-bit) available hard disk space (135 MB for companion software installation, 30 MB
for Adobe Reader, adequate space for data les)
DirectX 9 graphics device with WDDM 1.0 or later driver
22
Section 1 Scanner 3100 EFM
