Cameron Scanner 3100 EFM - Specifications

Specications
Table 1.1—General Specications
Approvals CSA (US and Canada)
Class I, Div. 1, Groups C and D, T4; Type 4 enclosure
ATEX 15ATEX1122X— Ex d [ia Ga] ib IIC T5 Gb (Tamb –40 degC to 70 degC; –40 degF to
158 degF)
IECEx SIR 15.0049X— Ex tb [ia Da] ib IIIC T100 degC Db (Tamb –40 degC to 70 degC; –40
degF to 158 degF)
(IP66 protection from dust and water)
ANSI 12.27.01 single seal (MVT ≤ 3000 psi)
ASME pressure vessel code (MVT ≤ 3000 psi); CRN 0F10472.5C
Environmental
Safety
Relative humidity: 0% to 95% non-condensing
Altitude: Up to 2000 meters
Enclosure Cast aluminum (less than 0.05% copper), painted with epoxy and polyurethane
Double-ended with single window
Dimensions: 5.43 in. wide, 11.27 in. deep, 10.76 in. tall with MVT
5 conduit ports including bottom sensor port, 3/4-in. FNPT connections
Weight Base unit (no MVT or batteries) 4.1 kg (9.1 lb)
Base + MVT and 2 batteries 8.3 kg (18.4 lb)
Base + MVT, direct-mount antenna, and 2 batteries 8.6 kg (19 lb)
System Power External user-supplied power supply (9 to 30 VDC, 150 mA) with internal lithium battery
backup.
For installations in Mexico, the power supply is limited to 9 to 24 VDC.
Two integral 7.2 V lithium stick-style battery packs, each containing two “D” batteries in series
(air transport regulations apply)
Real-time Clock Accurate within 2 minutes/year over temperature range
Lithium coin cell battery maintains clock during loss of system power (lithium content: 0.11 g)
Processor 32-bit dual-core ARM Cortex M4
Operating
Temperature
–40 degC to 70 degC (–40 degF to 158 degF)
LCD contrast is reduced below –30 degC (–22 degF)
WARNING: EXPLOSION RISK. Housing temperature must not exceed 70 degC (158 degF). Excessive
temperatures, which could result from ambient conditions combined with radiated and conductive heat from
the process, could cause the internal lithium battery to ignite or explode.
LCD Display/
Keypad
2.7-in. diagonal graphic display, 400 × 240 pixels
0.3-in. high characters
Displays up to 32 user-dened parameters (ve at a time), with auto-scrolling
External power indicator
Integral battery capacity indicators
Wireless communications indicator
Parameter status indicators
Congurable background (dark or light) and scroll frequency
4-button keypad for advancing the display; viewing communication settings, serial number,
and rmware version; and restoring factory default settings to the device
Memory 2.18 MB RAM for processing
512 KB non-volatile memory for conguration data
32+1 MB on-board system ash memory
48 MB on-board archive ash memory
15
Scanner 3100 EFM Section 1
