To replace a Scanner 3100 lithium battery pack,
1. Remove the cover from the enclosure (after securing the area per the warning on the previous page).
Note Proceed carefully when connecting the battery packs to the plastic receptacles to avoid damaging the connector
or bending pins. Using a pair of needle-nose pliers to grasp the plastic battery cable connector may aid in align-
ing the connector and receptacle pins when connecting and disconnecting battery packs.
2. Disconnect the battery leads of the spent battery from the connector on the back side of the display assembly.
3. Firmly grasp the battery pack and gently pull it forward to remove it from the enclosure.
4. Insert the fresh battery pack so that the battery lead end faces the rear of the battery compartment.
5. Connect the lead to the connector on the back side of the display assembly.
6. Repeat steps 2 through 5 to replace the other battery pack if required. Even if no external power is supplied, opera-
tions will continue uninterrupted as long as one battery pack remains connected.
7. Replace the enclosure cover.
86
Section 6 Scanner 3100 EFM
