5) Reassemble the parts in the reverse order from Step 4). Replace the ball bearings removed at Step 4) and Step 2) with new
type ball bearings (XG9-0787-000).
[Service parts]
No. Part Number Description Q'ty Fig.No.
1 Old XG9-0520-000 BEARING, BALL, MF106ZZS 2 -> 0 610
New XG9-0787-000 BEARING, BALL, LF1060ZZHP0P25L 0 -> 2
2 Old XD2-1100-502 RETAINING RING (E-TYPE) 4 -> 4
New
[Countermeasure cut-in serial numbers in factory]
Model Serial number
imagePRESS C10000VP Series ME US WBC10445
imagePRESS C10000VP Series ME EUO WEJ10547
imagePRESS C10000VP Series ME CN WBD00522
