SERVICING THE IMAGEPRESS SERVER WITH FURNITURE 142
REPLACING THE IMAGEPRESS SERVER IN THE FURNITURE
1. Make sure that the left side panel is removed from the imagePRESS Server.
2. Place the imagePRESS Server upright on the furniture stand. Slide the imagePRESS Server
forward just until its front panel is aligned with the back edge of the table top.
Use the handle on the stability bracket to lift the rear of the imagePRESS Server and slide it
forward.
3. Route the monitor cables (power and video) into the cutout in the back of the top panel. Pull
each cable out of the cutout in the top panel.
Video cable
Power cable
Top cutout
Back cutout
Top panel
To Next Page
