Canon imagePROGRAF iPF765 User Manual

6
Click the Page Setup tab to display the Page Setup
sheet.
7 In A Page Size, click the size of the original as specified in the application. In this case, click ISO A2.
8 Click Manual in the L Paper Source list.
9
Click the Layout tab to display the Layout sheet.
10 Select the A Page Layout check box.
11 Click Poster (2 x 2) in the A Page Layout list.
Note
• Follow the steps below to print only a portion of the poster as divided for printing.
• Click B Set under A Page Layout to display the Pages to Print dialog box.
• On the Pages to Print dialog box, clear the check boxes of the portion you do not want to print.
• Click OK to close the Pages to Print dialog box.
Printing Large Posters (Windows) iPF765
User's Guide
Enhanced Printing Options Tiling and multiple pages per sheet
140

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
