Canon imagePROGRAF iPF765 User Manual

5 In the Available Port list, select Standard TCP/IP Port.
6
Click New Port.
After the wizard starts, a window is displayed for the Welcome to the Add Standard TCP/IP Printer Port Wiz-
ard.
7 Click Next.
8 In Printer Name or IP Address, enter the printer's IP address. If the DNS is configured, you can also enter the
DNS Domain Name.
9 Follow the instructions on the screen to add a printer port.
10 Click Close to close the Printer Ports dialog box.
11 Make sure the printer port you added is displayed under Ports, and that the port is selected.
12 Click Close to close the printer properties window.
Configuring the Printer Driver Destination (Mac OS X)
Configuring the Printer Driver Destination (Mac OS X)
Specify the printer driver destination as follows if the printer's IP address is changed, or if you will use the printer over a
network connection instead of via USB connection.
• If you switch to printing in a TCP/IP network, or if the printer's IP address is changed, see "Configuring the Destina-
tion in TCP/IP Networks." →P.552
• If you switch to printing in a Bonjour network, see "Configuring the Destination for Bonjour Network." →P.553
Configuring the Printer's TCP/IP Network Settings With RemoteUI
Configuring the Printer's TCP/IP Network Settings With RemoteUI
Follow the steps below to configure the TCP/IP network settings.
When using an IPv4 IP address
1 Start the web browser and enter the following URL in the Location (or Address) box to display the RemoteUI
page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2 Select Administrator Mode and click Logon.
3 If a password has been set on the printer, enter the password.
4 Click Network in the Device Manager menu at left to display the Network page.
5 Click Edit in the upper-right corner of the TCP/IPv4 group to display the Edit TCP/IP Protocol Settings page.
6 Refer to the TCP/IP Settings Items table to complete the settings.
TCP/IP Settings Items
Item Details Default Setting
Use DHCP Activate this setting to use DHCP for configuring the IP address. Off
Use BOOTP Activate this setting to use BOOTP for configuring the IP address. Off
Use RARP Activate this setting to use RARP for configuring the IP address. Off
iPF765 Configuring the Printer Driver Destination (Mac OS X)
User's Guide
Network Setting Initial Settings
541

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
