Side
Side
a
Manual Pocket
Store printer manuals in this pocket.
b
Ethernet Port
Connect an Ethernet cable to this port. The lamp is lit if the Ethernet cable is connected correctly and communica-
tion is possible between the computer and printer.
c
USB Port
Connect a USB cable to this port. The printer is compatible with Hi-Speed USB connections.
d
Carrying Handles
When carrying the printer, have three people hold it by these handles on the back at both ends.
e
Power Supply Connector
Connect the power cord to this connector.
Side
iPF765
User's Guide
Printer Parts Printer parts
