Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead. .................................................................................................................................... 698
Wrong printhead. ............................................................................................................................................... 698
Printhead error ................................................................................................................................................... 698
No printhead ...................................................................................................................................................... 698
Execute printhead cleaning. .............................................................................................................................. 698
Cannot adjust printhead.
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.") →P.627
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.") →P.628
4. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).") →P.604
The Printhead cannot be aligned; highly
transparent film is loaded.
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).") →P.604
The Printhead is installed crooked. Straighten the Printhead as follows, and then execute Head Posi. Adj. again.
1. Press the OK button to clear the error.
2. Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment (Head Inc. Adj.).") →P.607
3. Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.).") →P.604
Wrong printhead.
Wrong printhead.
Cause Corrective Action
An incompatible Printhead has been installed. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") →P.629
Printhead error
Printhead error
Cause Corrective Action
There is a problem with the Printhead. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") →P.629
No printhead
No printhead
Cause Corrective Action
No Printhead is installed. Install the Printhead.
(See "Replacing the Printhead.") →P.629
Execute printhead cleaning.
Execute printhead cleaning.
Cause Corrective Action
The Printhead noz-
zles are clogged.
Follow these steps to clean the Printhead.
Cannot adjust printhead.
iPF765
User's Guide
Error Message Messages regarding printheads
698

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
