Canon imagePROGRAF iPF765 User Manual

ManageRemainRoll Barcodes Printer Operation After the Paper is Fed
On Printed The type and amount of paper left is automatically detected based on the barcode printed on the roll.
There is no need to specify the type and length of the paper.
Not printed A menu for selection of the paper type and length is automatically shown on the Display Screen.
Press ▲ or ▼ to select the type and length of paper loaded, and then press the OK button.
Note
• For details on types of paper to select, see the Paper Reference Guide. (See "Types of Paper.") →P.438
8
Holding it at the positions indicated, close the Roll Cover.
Note
• Cut the edge of the roll after the paper is advanced if it is soiled or if there are cuts from scissors or the blade after
removing creased edges. (See "Specifying the Cutting Method for Rolls.") →P.458
Changing the Type of Paper
Changing the Type of Paper
Follow these steps to change the type of paper specified on the printer after you have loaded paper.
If you will continue using this type of paper later, selecting Keep Paper Type > On will save the time and effort of con-
figuring the media type setting when you load the paper again. The current media type settings before you select On
will be automatically selected at that time. (See "Using the Same Type of Paper Regularly.") →P.450
Important
• For best printing results, the printer fine-tunes the print head height and the feed amount for each type of paper. Be sure to
select the type of paper to use correctly before printing.
• Because the printer fine-tunes the feed amount for each type of paper, the margins and the size of printed images may vary
depending on the type of paper used. If margins and the size of images are not as you expected, adjust the paper feed
amount.
(See "Adjusting the Feed Amount.") →P.611
Changing the Type of Paper
Note
• When you load a roll, a menu for selection of the type of paper is shown on the Display Screen. Select the type of paper, and
then press the OK button.
If no barcode has been printed on the roll and you have set ManageRemainRoll to On, specify the roll length after the type of
paper.
(See "Specifying the Paper Length.")
→P.451
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Paper tab (
).
iPF765 Changing the Type of Paper
User's Guide
Handling Paper Handling rolls
449

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
