Canon imagePROGRAF iPF765 User Manual

Preview
Preview
The Features of Preview ..................................................................................................................................... 209
Starting Preview ................................................................................................................................................. 209
Preview Main Window ........................................................................................................................................ 210
Dialog Area ........................................................................................................................................................ 212
Enlarge/Reduce the screen display ................................................................................................................... 213
Moving a Page ................................................................................................................................................... 213
Using the ruler .................................................................................................................................................... 213
Priority setting for rotating 90 degrees ............................................................................................................... 214
Printing with Selecting the Layout ...................................................................................................................... 215
Print on the Center ............................................................................................................................................. 217
Not Print Spaces at the Top/Bottom ................................................................................................................... 218
The Features of Preview
The Features of Preview
The main features of Preview are as follows.
• While viewing this screen, you can adjust layout settings of a document created with application software.
• You can not only adjust layout settings but also your changes will be instantly applied on the preview screen, and
you can print the preview screen as it is seen.
Note
• The media type, image size, detailed media settings, and the printer settings can cause the actual print output to differ from
the Preview settings.
Starting Preview
Starting Preview
Follow the procedure below to start the Preview.
1 Start the apllication software which you use.
2 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
• Normally, select Print from the File menu.
3
On the Main sheet, click on the Open Preview When
Print Job Starts check box.
Click the OK button to save the settings.
iPF765 The Features of Preview
User's Guide
Windows Software Preview
209

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
