Note
If you click the Print button with a graph selected, a message dialog box will appear asking if you want to continue
printing. If you click No, you will return to the application.
If you click the Print button with a page break set, a message dialog box will appear asking if you want to continue
printing. If you click No, you will return to the application. If you do not use the set page break, check the page break
preview and change the setting.
If you click the Print button with a page range set, a message dialog box will appear asking if you want to continue
printing. If you click No, you will return to the application. If you do not use the set page range, check the page break
preview and change the setting.
If you click the Print button with a worksheet or cell protected, a message dialog box will appear asking if you want
to continue printing. If you click No, you will return to the application. If you want to change the setting, remove the
protection from the worksheet or cell.
Print Entire Sheet (Excel)
Print Entire Sheet (Excel)
For resizing the entire sheet to fit the roll width. Choose this option to enlarge the currently displayed sheet before print-
ing.
1
Start Microsoft Excel.
2
If Start imagePROGRAF Print Plug-In is displayed, click it.
3
Click Print from the imagePROGRAF Print Plug-In toolbar/ribbon.
Important
When more than one worksheet is selected, the Printing Wizard cannot be run. Select only one worksheet and
click Print again.
If a print area is set, a confirmation message dialog box
will appear.
To print the entire sheet, cancel the setting of the print
area.
Print Entire Sheet (Excel)
iPF765
User's Guide
Windows Software Print Plug-In for Office
286
