Paper Information on Printer Dialog Box
Paper Information on Printer Dialog Box
On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure
printer driver media type setting.
Note
To display the Paper Information on Printer dialog box, on the Main pane, click Get Information by Media Type.(See "Main
Pane →P.332 ")
A Paper Source
Shows the Paper Source supported by the printer, as well as the type of paper loaded. To update the media type
setting in the printer driver, select the desired Paper Source option and click OK.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
The Paper Detailed Settings dialog box offers the following settings. For details on settings items, refer to the printer
driver help.
Note
To display the Paper Detailed Settings dialog box, on the Main pane, click Set by Media Type.(See "Main Pane →P.332 ")
iPF765
Paper Information on Printer Dialog Box
User's Guide
Mac OS X Software Printer Driver
335
