Output Method dialog box
Output Method dialog box
The Output Method dialog box allows you to select the Output Method and set the save settings when saving to the
box.
Note
To display the Output Method dialog box, on the Page Setup sheet, click Output Method. (Refer to "Page Setup
Sheet →P.196 ")
A Output Method
If Print is selected, the print job is saved to the printer hard disk after printing has finished.
If Save in mail box is selected, the print job is saved to the printer hard disk. If you choose Save in mail box, also
specify the destination personal box in the Mail box list.
If Print after reception is complete is checked, you can prevent degradation of print quality that occurs when
receiving a print job is interrupted and printing is aborted in the middle.
These can be selected as Print options.
B Name of data to be saved
To use the file name, choose Use file name.
Otherwise choose Enter name and enter a name in Name.
C
Mail box
Displays a list of mail boxes. If you choose Save in mail box, also specify the destination personal box from the
list.
D
Acquire Mail Box Name
When this is clicked, the box name acquired from the printer main unit is displayed in Mail box.
iPF765
Output Method dialog box
User's Guide
Windows Software Printer Driver
199

Table of Contents

Other manuals for Canon imagePROGRAF iPF765

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF765 and is the answer not in the manual?

Canon imagePROGRAF iPF765 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Pigment matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.8 mm
Maximum print size-
Maximum roll length18 m
Media width (rolls)254 - 914.4 mm
Media width (sheets)203.2 - 917 mm
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1, A2, A3
ISO B-series sizes (B0...B9)B1, B2, B4
CertificationCE, RoHS, ECO, WEEE
Storage mediaHDD
Internal storage capacity250 GB
Sound power level (standby)35 dB
Sound pressure level (printing)50 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet interface typeGigabit Ethernet
Sustainability certificatesENERGY STAR
Power requirements100 - 240V, 50/60Hz
Power consumption (standby)5 W
Power consumption (typical)140 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1304 x 1100 x 1062 mm
