G No Spaces at Top or Bottom (Conserve Paper)
Activate this setting to print the next image skipping blank areas above and below printable data in documents,
which enables you to conserve the paper.
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins →P.156
H Copies
Enter the number of copies to print, in a range of 1–999.
Reverse Order
Activate this option to print pages in reverse order.
I Page Options
Click to display the Page Options dialog box, which enables you to complete settings for printing the user name,
date, or page number in the header or footer.
Page Options Dialog Box →P.202
J Special Settings
If the printing results are not as you expected, click this option to change how printing is processed.
Special Settings Dialog Box →P.203
S Defaults
Click to restore all settings on the sheet to the default values.
Page Options Dialog Box
Page Options Dialog Box
The Page Options dialog box offers the following settings.
Note
To display the Page Options dialog box, on the Layout sheet, click Page Options.(See "Layout Sheet →P.201 ")
A
Print Date
Select where the date is printed, as desired. To print the time as well, select B Print Time Also.
C
Print User Name
Select where the user name is printed, as desired.
D
Print Page Number
Select where the page number is printed, as desired.
Page Options Dialog Box
iPF765
User's Guide
Windows Software Printer Driver
202

Table of Contents

Other manuals for Canon imagePROGRAF iPF765

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF765 and is the answer not in the manual?

Canon imagePROGRAF iPF765 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Pigment matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.8 mm
Maximum print size-
Maximum roll length18 m
Media width (rolls)254 - 914.4 mm
Media width (sheets)203.2 - 917 mm
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1, A2, A3
ISO B-series sizes (B0...B9)B1, B2, B4
CertificationCE, RoHS, ECO, WEEE
Storage mediaHDD
Internal storage capacity250 GB
Sound power level (standby)35 dB
Sound pressure level (printing)50 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet interface typeGigabit Ethernet
Sustainability certificatesENERGY STAR
Power requirements100 - 240V, 50/60Hz
Power consumption (standby)5 W
Power consumption (typical)140 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1304 x 1100 x 1062 mm
