Canon imagePROGRAF iPF765 User Manual

Printer Specifications
Printer Specifications
Specifications ..................................................................................................................................................... 708
Print Area ............................................................................................................................................................ 710
Specifications
Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply 100–120 V AC (50/60 Hz), 220–
240 V AC (50/60 Hz)
Power consumption During operation 140 W max.
Sleep mode 100–120 V: 5 W max.
220–240 V: 6 W max.
Off 0.5 W max. (*1)
Operating noise (*2) During operation (sound pressure level/LWAd) Approx. 50 dB (A) (6.6 bels)
Standby 35 dB (A) max.
Operating environment Temperature 15–30°C (59–86°F)
Humidity 10–80%, non-condensing
Dimensions (W × D × H) Printer and Stand When the Output Stacker is not used 1,304×708×1,062 mm
(51.3×27.9×41.8 in)
Regular position 1,304×887×1,062 mm
(51.3×34.9×41.8 in)
Extended position A
Extended position B 1,304×1,100×1,062 mm
(51.3×43.3×41.8 in)
Weight Printer and Stand (not including the Printhead and ink tanks) Approx. 64.1 kg (141.3 lb)
Space for installation (W × D ×
H)
Printer and Stand 1,704×1,700×1,362 mm
(67.1×66.9×53.6 in)
Applicable standards International Energy Star Program, Law on Promoting Green Purchasing, Eco Mark, GPN, RoHS, Eco
Declaration, WEEE, U.S. presidential directives, Chinese RoHS
*1: The printer uses a trace amount of power even when turned off. To stop all power consumption, turn off the printer and unplug the power
cord.
*2: Calculation based on ISO 7779. Operating conditions: On the Main sheet of the printer driver, Media Type > Plain Paper, Advanced
Settings > Print Priority > Line Drawing/Text, and Print Quality > Standard.
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi horizontally (*1) × 1200 dpi vertically
Printhead PF-04
Number of nozzles MBK: 5120; Others: 2560 each color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Specifications
iPF765
User's Guide
Specifications Printer Specifications
708

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
