Canon imagePROGRAF iPF765 - Roll Cover (Inside); Carriage

Roll Cover (Inside)
Roll Cover (Inside)
a Roll Holder
Load the roll on this holder.
b Holder Stopper
Secure rolls on the Roll Holder with this part.
c Roll Loading Slots
Slide the Roll Holder along these slots.
d
Roll Holder Slot
Load the Roll Holder into this holder slot.
Carriage
Carriage
Roll Cover (Inside)
iPF765
User's Guide
Printer Parts Printer parts
