N Roll Paper Options
Complete optional roll paper settings. Click to display the Roll Paper Options dialog box.
Under A Automatic Cutting, you can specify Yes or No and Print Cut Guideline.
Cutting Roll Paper After Printing →P.171
Select B Banner Printing when printing multiple pages continuously.
Printing Multiple Pages Continuously →P.129
P Output Method
Click to display the Output Method dialog box, which enables you to complete the Output Method and Name of
data to be saved settings.
Output Method dialog box →P.199
O Size Options
Click to display the Paper Size Options dialog box, which enables you to register additional paper sizes or select
the size system for use.
Paper Size Options Dialog Box →P.200
S Defaults
Restores all settings on the sheet to the default values.
Page Setup Sheet
iPF765
User's Guide
Windows Software Printer Driver
198

Table of Contents

Other manuals for Canon imagePROGRAF iPF765

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF765 and is the answer not in the manual?

Canon imagePROGRAF iPF765 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Pigment matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.8 mm
Maximum print size-
Maximum roll length18 m
Media width (rolls)254 - 914.4 mm
Media width (sheets)203.2 - 917 mm
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1, A2, A3
ISO B-series sizes (B0...B9)B1, B2, B4
CertificationCE, RoHS, ECO, WEEE
Storage mediaHDD
Internal storage capacity250 GB
Sound power level (standby)35 dB
Sound pressure level (printing)50 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet interface typeGigabit Ethernet
Sustainability certificatesENERGY STAR
Power requirements100 - 240V, 50/60Hz
Power consumption (standby)5 W
Power consumption (typical)140 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1304 x 1100 x 1062 mm
