g
Paper Alignment Line
An orange line for alignment of paper.
h
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
i
Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
j
Cutter Unit
A round-bladed cutter for automatic roll cutting.
k
Cutter Rail
The Cutter Unit passes over this rail to cut paper.
l
Output Tray
All printed documents are ejected from this slot.
m
Ejection Guide
Guides printed documents as they are ejected.
n
Top Cover
Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed. (See
"Top Cover (Inside).") →P.521
o
Width Guide
When loading the sheets , move the guide to match the paper size.
p
Stand
A stand that holds the printer. Equipped with casters to facilitate moving it. (See "Stand.") →P.524
