Canon imagePROGRAF iPF765 User Manual

3
When the program has finished communicating with the
printer, the screen moves to display Update Media
Types - Confirm Update. Confirm the information re-
ceived from the printer.
To update click the Execute button.
Important
• When setting a data to the printer that differs from the data to be updated, the selected media information file is
updated. When you would like to remain the data that is set to the printer, click the Cancel button.
4
Communication with the printer starts and the following
dialog box is displayed.
Important
• Do not attempt to print or turn the printer off while the program is communicating with the printer.
Caution
•
When the program cannot communicate with the printer,
the following warning message is displayed.
iPF765 Updating Media Types
User's Guide
Mac OS X Software Media Configuration Tool
435

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
