Note
• For details on supported sizes and types of rolls, see Paper Sizes or the Paper Reference Guide. (See "Paper Sizes.")
→P.438 (See "Types of Paper.") →P.438
• To view instructions as you attach the Roll Holder, press the Navigate button. (See "How to View Instructions With Navigate.")
→P.483
1
Lift the Holder Stopper lever (a) from the shaft side to
unlock it. Holding the Holder Stopper at the position in-
dicated (b), remove it from the Roll Holder.
2
Insert the respective attachments for the roll paper core on the Roll Holder and Holder Stopper.
•
Using rolls with a 2-inch paper core
Holder Stopper (Left Side) Roll Holder (Right Side)
Align the tips (a) of the 2-Inch Paper Core Attachment with the holes (b) of the Holder Stopper and insert it firmly. No attachment is
needed.
Attaching the Roll Holder to Rolls
iPF765
User's Guide
Handling Paper Handling rolls
444
To Next Page
