Canon imagePROGRAF iPF765 User Manual

• Off
The printer is off or is operating normally.
d Power button (green)
Turns the printer on and off. (See "Turning the Printer On and Off.") →P.19
The Power button is lit when the printer is on or in Sleep mode.
e Stop button
Cancels print jobs in progress and ends the ink drying period.
f Navigate button
Enables you to check instructions for loading and removing paper or replacing ink tanks or printheads, as well as
other operations. (See "How to View Instructions With Navigate.") →P.483
g
Arrow buttons
•
◀ button
Press this button on the Tab Selection screen to move to another tab.
In menu items requiring numerical input, press this button to move to another digit.
• ▲ button
Press this button when viewing menus to display the next menu item or setting value.
•
▶ button
Press this button on the Tab Selection screen to move to another tab.
In menu items requiring numerical input, press this button to move to another digit.
• ▼ button
Press this button when viewing menus to display the next menu item or setting value.
h OK button
Press this button on the Tab Selection screen to display the menu of the tab shown.
Pressing this button in menu items of each tab for which
is displayed at left will move to the lower level of the
menu item, enabling you to execute menu commands or set menu values.
Also press this button if the Display Screen indicates to press the OK button.
i Back button
Displays the screen before the current screen.
j Menu button
Displays the Tab Selection screen. (See "Menu Settings.") →P.500
k Load button
Press this button when loading or replacing paper.
(See "Loading Rolls in the Printer.") →P.446
(See "Loading Sheets in the Printer.") →P.465
l
Feed button
Pressing this button when rolls are loaded enables you to reposition the paper. (See "Feeding Roll Paper Manual-
ly.") →P.455
m
Cut
button
Pressing this button when rolls are loaded cuts the paper, if you have specified Automatic or Eject in Cutting
Mode in the Control Panel menu. (See "Specifying the Cutting Method for Rolls.") →P.458
n Cut Sheet lamp
(green)
Lit when sheets are selected as the paper source.
o Roll Media lamp
(green)
Lit when rolls are selected as the paper source.
iPF765
Control Panel
User's Guide
Control Panel Operations and Display Screen
479

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
